Absolute Linear Grating Scale RLA100

RLA-100 Series Optical Linear Encoders offer precisemeasurements up to 3040 mm

Email:

Inquire Now
File Download

 Contact US !

View similar products

Linear Grating Scale

Tag list

Grating Scale

  • Detailed

  • RLA-100 Series Optical Linear Encoders offer precisemeasurements up to 3040 mm, supporting Biss-C,SSl,Fanuc, and Panasonic protocols for reliable positionfeedback, Achieving a remarkable accuracy of ±3um and state-of-the-art resolution down to 5nm, these encoders are ideal for precision applications infine machinery.

    Model

    RLA100 Absolute Enclosed Linear Grating Ruler

    Measurement

    140, 240, 340, 440, 540, 640, 740, 840, 940, 1040, 1140, 1240, 1340, 1440, 1540, 1640, 1740, 1840, 1940, 2040, 2140, 2240, 2340, 2440, 2540, 2640, 2740, 2840, 2940, 3040 (Unit: mm)

    Accuracy

    ±3μm; ±5μm

    Pitch

    20μm

    Resolution

    5nm; 10nm; 50nm; 100nm

    Supply Voltage

    5V±5%

    Electrical Output Interface

    SSI

    Biss - C

    Fanuc

    Panasonic

    Mitsubishi

    DRIVE - CLiQ

    Plug

    DB9 pin; DB15 pin

    Operating Temperature

    0～50℃

    Protection Class

    IP53, with compressed air IP64
