Digital Output-RLC63D
View similar products
Tag list
- Detailed
-
Incremental encoder and absolute encoder are optional for the digital signal output type.
Output signals are square wave ABZ signals or Gray code signals.
Measurement range is up to 2500mm.
Linear accuracy: 0.05% FS. Resolution based on the different configuration can reach 0.001mm / pulse in maximum.
Working temperature: -30 ° C-+90 ° C.
Model RLC63D Product Type Draw-wire Sensor (Incremental) Box Size 63*63mm Measuring Range 0 - 2500mm Output Type Digital Output Supply Voltage DC5V/8 - 26V Output Form Voltage Push - Pull Open Collector Drive Output (5V) Wide - Voltage Drive (8 - 26V) Sensor Resolution (mm) 0.15 0.075 0.06 0.041 0.03 Encoder Resolution（ppr） 1000 2000 2500 3600 5000 Reciprocating Frequence 50Hz Max. Reciprocating Speed 1000mm/s Operating Temperature -30～90℃ Protection Rating IP54 Drawing Dimension Reference：
