Hollow Shaft Encoder

Tag list

Hollow Shaft Encoder

Detailed

Basic Information	Model	RAA130B60
Basic Information	Product Type	Photoelectric Single - turn Encoder
Mechanical Parameters	Outer Diameter	130mm
	Shaft Diameter	60mm （Hollow Shaft）
	Maximum Speed	3000 r/min
	Shaft Load	Radial (≤40N) ; Axial (≤20N)
Electrical Parameters	Resolution	16-21 bit Single - turn
	Supply Voltage	DC5V / DC10-30V
	Output Code	Binary Code / Gray Code
Environmental Parameters	Operating Temperature	-40~65℃
Environmental Parameters	Protection Rating	IP54

Asynchronous Serial	Communication Protocol	RS422 / RS485 / RS232
	Communication Interface	Timed Transmission; Timed + Clear; Pulse Handshake; Handshake + Clear; Bus Command; Bus + Clear; MODBUS
	Baud Rate	115200 / 57600 / 38400 / 19200 / 9600 / 4800
	Update Rate (Hz)	2000 / 1000 / 500 / 400 / 200 / 100 / 50 / 20
Synchronous Serial	Communication Protocol	SSI / CANopen / BiSS - C

Drawing Dimension Reference：

None
